ecancermedicalscience

Case Report

Literature meta-analysis of zosteriform cutaneous metastases from melanoma and a clinico-histopathological report from India

Savita Chaudhary 1, Cherry Bansal 2 and Ayanat Husain 3

1 Department of Dermatology, Era’s Lucknow Medical College and Hospital, Lucknow, Uttar Pradesh, India

2 Department of Pathology, Era’s Lucknow Medical College and Hospital, Lucknow, Uttar Pradesh, India

3 Department of Surgery, Era’s Lucknow Medical College and Hospital, Lucknow, Uttar Pradesh, India

Correspondence to: Savita Chaudhary. Email: savitagarg3@gmail.com


Abstract

Cutaneous metastases in patients with malignant tumours are an important clue to tumour progression or even the first manifestation of malignancy. Among the various topographic patterns of cutaneous metastasis, the zosteriform pattern of metastasis is rare, and very few cases have been published. Various theories have been proposed for this zosteriform pattern of metastases, but none have been proved. We collected the available PubMed articles on zosteriform skin metastasis from cutaneous melanoma published since 1970 and reviewed the cases, including our own case. Melanoma presents with cutaneous metastasis in up to 44% of patients. Clinicians treating oncology patients should consider zosteriform skin metastasis in the differential diagnosis of zosteriform lesions to avoid inadequate diagnosis and management.

Keywords: carcinoma, skin neoplasm, secondary, melanoma, herpes zoster, meta-analysis.


Introduction

Skin metastases are very common among patients with melanoma. Skin is involved as the site of metastasis in approximately 10% of metastases from all primary neoplasms, and up to 44% of malignant melanoma has cutaneous metastasis [1].

From a clinical point of view, the most common presentations of cutaneous metastatic disease are papules and nodules, solitary or widespread, sometimes ulcerated. However, a wide morphological spectrum of lesions has been described, including erythematous patches or plaques, inflammatory erysipela-like lesions, diffuse sclerodermiform lesions with induration of the skin (‘en cuirasse’ metastatic carcinoma), telangiectatic papulovesicles, purpuric plaques mimicking vasculitis, and alopecia areata-like scalp lesions [14]. Malignancies with zosteriform cutaneous metastases originate in skin, blood vessels, blood, and viscera [5].

The zosteriform pattern has been described in few cases; a recent meta-analysis reviewed 56 cases published in the English literature since 1970 [6]. Several theories have been proposed in the literature to explain the pathogenetic mechanism of zosteriform dissemination, but none have been adequately proved.

In this article, we report a case of cutaneous melanoma with zosteriform metastasis, and we meta-analyse the available literature about zosteriform metastasis secondary to melanoma. The aim is to detail the morphological pattern of zosteriform metastasis secondary to melanoma.


Case Report

A 70-year-old male presented to the dermatology department of Era’s Lucknow Medical College, Lucknow, India, with a chief complaint of painful nodular lesions progressively increasing in size and number over the medial and anterior aspect of the thigh since one month before.

On examination of the medial aspect of the left thigh, multiple papulonodular lesions of sizes varying from 0.5 cm × 0.5 cm to 1 cm × 2 cm were seen in dermatomal segment L2–L3, which coalesced to form an indurated plaque of size 10 cm × 15 cm with an irregular, erythematous surface and an ill-defined border (Figure 1).

Figure 1: Left thigh medial aspect showed multiple papulonodular lesions that coalesced to form a plaque in dermatomal segment L2–L3.

An examination of the inguinal region revealed multiple discrete, firm, non-tender, mobile lymph nodes on the left side varying from 1 to 4 cm in size. Fine needle aspiration cytology smears from the lymph nodes showed melanoma cells with occasional pigmentation.

On complete examination of the patient, two non-tender lesions were found on the sole of the left foot (Figure 2). One was an ulcerated, ill-defined, pigmented lesion of 4 × 5 cm in size, present laterally on the middle part, and the other was a pigmented firm plaque of 2 cm × 3 cm in size with well-defined margins and a raised surface. These lesions had been present for one year and were progressively increasing in size, and the larger lesion had ulcerated one month before the examination.

Figure 2: The sole of the left foot showed a larger ulcerated, ill-defined, pigmented lesion of size 4 cm × 5 cm, present laterally, and a smaller pigmented firm plaque of size 2 cm × 3 cm with well-defined margins and a raised surface, present medially.

A provisional diagnosis of herpes zoster left thigh L2–L3 was considered, but the history did not corroborate with the disease. The lesion on the left thigh was not vesiculobullous, the plaque was firm on palpation, and the corresponding lymph nodes were also enlarged, firm, and multiple. Diagnostic punch biopsies from the left thigh plaque and the sole lesion were done. The tissue bled profusely and was very friable.

A histopathological examination from the primary site with clinically evident ulcerated surface showed a lesion simulating acantholytic bulla in the scanner view (Figure 3a). The keratin layer thickness of the plantar surface was normal and exhibited evidence of ulceration with neutrophilic and fibrinous exudation toward the surface (Figure 3b). Proliferation of single atypical pigmented melanocytes was seen in the epidermal layers. The single melanocytes and the cell nests were distributed as runs of the cells in the papillary and deep reticular dermis (Clark level IV lesion). Asymmetrical inflammatory infiltrate of lymphocytes was present around tumour nests and showed crushing artefact. An increase in dermal blood vessels with proliferating new vessels was present in the dermis (Figure 3c). The maturation sequence for melanocytes as they descend into the dermis was not very evident. Melanoma cells were seen as large cells with abundant eosinophilic cytoplasm, vesicular nuclei, and very large, eosinophilic nucleoli.

The haematoxylin and eosin-stained section from the non-ulcerated area of the primary site showed architectural changes within the epidermis, with poor circumscription of melanocytes, which were present as intra-epidermal nests and single cells beyond the basal level, often exhibiting cytoplasmic melanin pigment (Figure 3d). The melanocytes had haphazard and aberrant distribution in the dermis, with a perivascular arrangement at some places. The tumour cells had a large, irregular nucleus with vesicular chromatin, prominent eosinophilic nucleoli and visible intracellular melanin pigment. Brisk mitotic activity was present.

Figure 3: a. Photomicrograph from the primary origin ulcerated site simulated acantholytic bullous lesion in the scanner view (H & E; 100×). b. Photomicrograph exhibiting neutrophilic and fibrinous exudate toward the ulcerated surface (arrow). Tumour cell nests are present deep in the reticular dermis (H & E; 200×). c. Proliferation of single atypical pigmented melanocytes and nests (black arrow) seen in the epidermal layers. Increase in dermal blood vessels with proliferating new vessels present in the dermis (blue arrow) (H & E; 100×). d. Photomicrograph showing dense infiltration of melanoma cells with pigment at places. Atypical cells have descended deep into the reticular dermis (H & E; 100×).

The histological appearance of melanoma metastasis in the thigh skin differed from that of the primary melanoma site by the absence of junctional activity, non-involvement of the epidermis, absence of inflammatory infiltrate, and different tumour cell morphology. There was little tendency for maturation of melanocytes with progressive descent through the dermis. Nests of atypical cells were seen in the reticular and deep dermis. Dermal invasion was characterised by proliferation of hyperchromatic melanocytes in fairly symmetrical small and large cellular nodules. The pattern to aggregate around eccrine structures and small blood vessels was clearly appreciable. A focus of perineural aggregate was also seen in the section. However, the nodules did not involve the subcutis included in the section examined. Cytologically, unlike the primary site, the cells were uniformly atypical with hyperchromatic, irregular nuclei with dense nuclear chromatin and inconspicuous nucleoli. No melanin pigment was visible in the melanocytes at the metastatic site. Mitotic activity was low and very occasional mitotic figure was seen. The overlying epidermis was largely unremarkable (Figure 4). Immunohistochemistry for HMB-45 was positive in tumour cells.

Figure 4: Photomicrograph from the metastatic site showing a circumscribed tumour nodule of hyperchromatic tumour cells in dermis with no junctional activity (green arrow). A small tumour nest (blue arrow) and perineural tumour focus (black arrow) are seen in upper dermis (H & E; 100×).

On the basis of clinical presentation and histopathological examination, the case was diagnosed as melanoma of the left sole with zosteriform cutaneous metastasis.

A literature meta-analysis of melanoma cases with zosteriform metastases was performed.

We reviewed the literature from Pubmed published since 1970 and found very few reported cases of melanoma with zosteriform cutaneous metastases. To the best of our knowledge, no case report has been published from India. To date, 12 cases have been reported, including our case, as shown in Table 1. Out of the 12 patients, nine were males and three were females, that is, 75.0% males and 25.0% females. Most of the patients were in the sixth and seventh decade of life. The site of melanoma varied widely: pre-auricular (one case), shoulder (one case), interscapular (one case), chest (one case), back (three cases), lumbar region (two cases), right hip (one case), unknown primary (two cases), and sole in the present case, and this is the first case of melanoma of the sole ever reported having zosteriform cutaneous metastasis. The time from the first diagnosis to zosteriform metastasis varied from simultaneous (as in our case) to five years. The sites of metastatic skin lesions as described in previous studies were the scalp (one case), chest (three cases), forearm (one case), trunk (six cases) and back (one case), and thigh in our case. Vesiculobullous lesions were present in six cases (50%), but in our case, multiple nodular lesions were seen, coalescing to form a plaque. Metastatic involvement with regional lymph nodes was seen in 8 out of 12 cases including the present case (66.7%). The overall patient outcome was poor, the mean survival from skin involvement ranged from 1 to 36 months. Cutaneous melanomas account for 19.05% (12/63) of zosteriform metastases reported in the literature. Zosteriform localisations usually arise in the same topographic locations as the primary melanoma.

Table 1: Review of melanoma cases presenting with zosteriform metastasis.


Discussion

Skin metastases appear in 10% of cancer patients [1]. Melanoma presents with skin metastasis (up to 44% cases) [1], and up to 1% of patients presenting with metastasising melanoma do not have a detectable primary tumour [7, 14]. Many different malignant tumours can metastasise to the skin, but the most common primary sources are the breast, stomach, lung, and uterus [13]. These lesions usually present as firm papules or nodules, both of which may ulcerate; occasionally, they are inflammatory, sclerotic, bullous or vesicular.

Topographically cutaneous lesions may present at any site near or far from the area of primary malignancy, but zosteriform cutaneous metastasis is a rare occurrence. Zosteriform metastasis may be painful, tender, or pruritic and consists of vesicles on a background of erythema, imitating the appearance of shingles. The vesicles are commonly confined to single unilateral dermatome, adding to the potential of misdiagnosis. Paola Savoia et al [6] analysed 56 cases of zosteriform metastases secondary to various tumours in 2009. We reviewed PubMed articles related to zosteriform cutaneous metastases and found six more cases of zosteriform metastases reported by various authors to date. To the best of our knowledge, 63 cases (including our case) of zosteriform cutaneous metastasis have been reported, out of which 12 (19.05%) were secondary to melanoma [1520]. Several theories have been proposed to explain the mechanism of the zosteriform distribution of metastases. Some of the patients described in the literature had a history of a zoster infection in the same dermatome in which metastatic lesions were subsequently observed [8, 2126]. In these cases, the zosteriform pattern could be a consequence of a Koebner or Koebner-like phenomenon in a site of diminished resistance of the skin [8, 23, 24]. More recently, it has been suggested that neural alteration caused by the herpes virus resulted from an impairment of the immunological function of the overlying skin that, consequently, could be more receptive to metastatic cell homing [27]. Several authors showed evidence of viral DNA from the skin of patients with zosteriform metastases [8, 2126], and they did not refer to previous varicella zoster virus infections. Other possibilities to explain the spread of tumour cells with a zosteriform pattern include a direct invasion from underlying structures (in the case of internal cancer) [28], surgical implantation of neoplastic cells into the skin [29], and invasion of the perineural lymphatic vessels or the dorsal root ganglion fenestrated vasculature. The clinical evidence, reported by several authors, of tissue swelling and the histopathologic demonstration of enlarged lymphatic vessels with focal neoplastic embolism support the hypothesis of metastatic spread through the lymphatic system [15, 30, 31]; widespread lymphatic obstruction by tumour cells can result in retrograde flow that spreads malignant cells into the skin [11]. In our opinion, this last hypothesis seems more apt to describe the pathogenesis of zosteriform metastases in our patient. In fact, all these patients demonstrated involvement of regional lymph nodes, with concomitant development of cutaneous metastases. In summary, cutaneous metastases with zosteriform pattern are rare entities, and among these, ones due to melanoma are the rarest. Hence, the published data about zosteriform melanoma metastases are too scanty and incomplete to minutely define this entity [6]. In our case, histopathological examination played an important role in making the diagnosis and ruling out herpes zoster.


Conclusion

In patients presenting with melanoma and lesions of zosteriform pattern, an accurate medical history could be of primary importance for the right classification of the disease and for treatment choice. Moreover, clinicians treating oncology patients should consider this rare form of cutaneous involvement in the differential diagnosis of zosteriform lesions to avoid inadequate diagnosis and management.


References

1. Lookingbill DP, Spangler N and Helm KF (1993) Cutaneous metastases in patients with metastasis carcinoma: a retrospective study of 4020 patients J Am Acad Dermatol 29 228–36 DOI: 10.1016/0190-9622(93)70173-Q

2. Schwartz RA (1995) Histopathologic aspect of cutaneous metastatic disease J Am Acad Dermatol 33 649–57 DOI: 10.1016/0190-9622(95)91288-6 PMID: 7545706

3. Saeed S, Keehn CA and Morgan MB (2004) Cutaneous metastasis: a clinical, pathological and immunohistochemical appraisal J Cutan Pathol 31 419–30 DOI: 10.1111/j.0303-6987.2004.00207.x PMID: 15186430

4. Sariya D, Ruth K, Adams-McDonnell R, et al (2007) Clinicopathologic correlation of cutaneous metastases: experience from a cancer center Arch Dermatol 143 613–20 DOI: 10.1001/archderm.143.5.613 PMID: 17515511

5. Itin PH, Lautenschlager S and Buechner SA (1995) Zosteriform metastases in melanoma J Am Acad Dermatol 32 854–7 DOI: 10.1016/0190-9622(95)91546-X PMID: 7722043

6. Paola Savoia, Paola Fava, Tommaso Deboli, et al (2009) Zosteriform cutaneous metastases: a literature meta-analysis and a clinical report of three melanoma cases Dermatol Surg 35 1355–63 DOI: 10.1111/j.1524-4725.2009.01241.x PMID: 19508408

7. Martínez Fernández M, Pedro Sanchez Sambucety and Manuel Angel Rodriguez Prieto (2004) Zosteriform metastatic melanoma Int J Dermatol 43 666–7 DOI: 10.1111/j.1365-4632.2004.02201.x PMID: 15357747

8. Zalaudek I, Leinweber B, Richtig E, et al (2003) Cutaneous zosteriform melanoma metastases arising after herpes zoster infection: a case report and review of the literature Melanoma Res 13 635–9 DOI: 10.1097/00008390-200312000-00016 PMID: 14646630

9. Stern JB, Haupt HM and Aaronson CM (1990) Malignant melanoma in a speckled zosteriform lentiginous nevus Int J Dermatol 29 583–4 DOI: 10.1111/j.1365-4362.1990.tb03474.x PMID: 2242948

10. North S, Mackey JR and Jensen J (1998) Recurrent malignant melanoma presenting with zosteriform metastases Cutis 62 143–6 PMID: 9770130

11. Kondras K, Zalewska A, Janowski P and Kordek R (2006) Cutaneous multifocal melanoma metastases clinically resembling herpes zoster J Eur Acad Dermatol Venereol 20 470–2 DOI: 10.1111/j.1468-3083.2006.01464.x PMID: 16643157

12. Galindo E, Sánchez de Paz F and Pérez I (2000) Malignant melanoma with zosteriform metastases Cutis 65 312–4 PMID: 10826094

13. Evans AV, Child FJ and Russell-Jones R (2003) Zosteriform metastasis from melanoma Br Med J 326 1025–6 DOI: 10.1136/bmj.326.7397.1025

14. Assmann A, Farthmann B, Burkhardt O, et al (2000) Cerebriform nodular amelanotic metastases of malignant melanoma: a challenge in differential diagnosis of a rare variant Br J Dermatol 142 533–6 DOI: 10.1046/j.1365-2133.2000.03372.x PMID: 10735966

15. Bassioukas K, Nakuci M, Dimou S, et al (2005) Zosteriform cutaneous metastases from breast adenocarcinoma J Eur Acad Dermatol Venereol 19 593–6 DOI: 10.1111/j.1468-3083.2005.01205.x PMID: 16164715

16. Hodge SJ, Mackel S and Owen LG (1979) Zosteriform inflammatory metastatic carcinoma Int J Dermatol 18 142–5 DOI: 10.1111/j.1365-4362.1979.tb04492.x PMID: 422313

17. Hudson CP, Hanno R and Callen JP (1984) Cutaneous angiosarcoma in a site of healed herpes zoster Int J Dermatol 23 404–7 DOI: 10.1111/j.1365-4362.1984.tb03202.x PMID: 6541210

18. Niedt GW and Prioleau PG (1988) Kaposi’s sarcoma occurring in a dermatome previously involved by herpes zoster J Am Acad Dermatol 112 448–51 DOI: 10.1016/S0190-9622(88)70068-7

19. Torne R and Umbert P (1986) Hodgkin’s disease presenting with superficial lymph nodes and tumors of the scalp Dermatologica 172 225–8 DOI: 10.1159/000249341

20. Aloi FG, Appino A and Puiatti P (1990) Lymphoplasmocytoid lymphoma arising in herpes zoster scars J Am Acad Dermatol 22 130–1 DOI: 10.1016/S0190-9622(08)80015-1 PMID: 2298951

21. Ruocco V, Ruocco E, Ghersetich I, et al (2002) Isotopic response after herpes virus infection: an update J Am Acad Dermatol 46 90–4 DOI: 10.1067/mjd.2002.118362 PMID: 11756952

22. Bauzá A, Redondo P and Idoate MA (2002) Cutaneous zosteriform squamous cell carcinoma metastasis arising in an immunocompetent patient Clin Exp Dermatol 27 199–201 DOI: 10.1046/j.1365-2230.2002.01006.x PMID: 12072007

23. Hazelrigg DE and Rudolph AH (1977) Inflammatory metastatic carcinoma Dermatol 113 69–70 PMID: 831626

24. Kamisawa T, Takahashi M, Nakajima H and Egawa N (2006) Gastrointestinal Zosteriform metastases to the skin J Gastroenterol Hepatol 2 620 DOI: 10.1111/j.1440-1746.2006.04345.x

25. LeSueur BW, Abraham RJ, DiCaudo DJ and O’Connor WJ (2004) Zosteriform skin metastases Int J Dermatol 43 126–8 DOI: 10.1111/j.1365-4632.2004.02112.x PMID: 15125503

26. Laksmi C, Pillai SB, Sharma C and Srinivas CR (2010) Carcinoma en cuirasse of the breast with zosteriform metastasis Indian J Dermatol Venerol Leprol 76 215 DOI: 10.4103/0378-6323.60544

27. Rao R, Balachandran C and Rao L (2010) Zosteriform cutaneous metastases: a case report and brief review of literature Indian J Dermatol Venerol Leprol 76(4) 447 DOI: 10.4103/0378-6323.66605

28. Eichinger J, George B and Myhand R (2011) Cutaneous metastatic rectal carcinoma masquerading as herper zoster South Med J 104(3) 233–5 DOI: 10.1097/SMJ.0b013e31820bfd04 PMID: 21297531

29. Virmani NC, Sharma YK, Paniker NK, et al (2011) Zosteriform skin metastases: clue to an undiagnosed breast cancer Indian J Dermatol 56(6) 726–7 DOI: 10.4103/0019-5154.91838

30. Dincer D, Tunca M, Akar A and Kurt B (2011) Zosteriform cutaneous metastasis of renal cell carcinoma Indian J Dermatol Venereol Leprol 77(3) 340–2 DOI: 10.4103/0378-6323.79723 PMID: 21508581

31. Chandelwale SS, Gore CR, Buch AC and Misal SS (2011) Zosteriform cutaneous metastasis: a primary manifestation of carcinoma breast, rare case report Indian J Pathol Microbiol 54(4) 863–4 DOI: 10.4103/0377-4929.91539 PMID: 22234145
